Andman S3 150-330 Water Processing Treatment Pumps
Andman S3 150-330 centrifugal pumps are belongs to S series single-stage centrifugal pumps, distinguished by an open-impeller design (vs. the closed/semi-open variants used in other S-series models).
Andman common S3 Paper Pulp Stock Pump Models:
S3 100-350.3, S3 125-400, S3 150-400.3, S3 200-380, S3 150-470.3, S3 200-470.3, S3 250-430.3, S3 350-470.3 etc.
Andman S3 Pumps Primarily used for transporting:
Clean liquids
Liquids containing small amounts of solid particles
Pulp suspensions
Process liquids
S3 150-330.3 Paper Stock Pumps Typical industries:
Pulp & Paper
Chemical Industry
Food Industry
Water Supply
Wastewater Treatment
Energy Industry
Andman S3 150-330 Paper Pumps Spare Parts List
| Pos. | Part Name |
| 102 | Pump Casing / Volute Casing |
| 135.1 | Front Insert / Front Lining |
| 135.2 | Rear Insert / Rear Lining |
| 161 | Casing Cover / Housing Cover |
| 230 | Impeller |
| 321 | Bearing |
| 350 | Bearing Bracket / Bearing Housing |
| 360.1 | Bearing Cap |
| 360.2 | Bearing Cap |
| 400 | Gasket |
| 411 | O-ring / Seal Ring |
| 412 | Gasket Ring |
| 433 | Mechanical Seal |
| 452 | Stuffing Box / Gland |
| 524 | Shaft Sleeve |
| 642 | Oil Sight Glass |
| 922 | Impeller Nut |
Andman S3 150-330 Centrifugal Paper Pumps Materials Specification
| Pump Part | Material | Material Standard |
| Impeller | Stainless Steel / Duplex Stainless Steel | 1.4021 / 1.4460 / 1.4462 / 1.4517 |
| Pump Casing | Cast Iron / Stainless Steel | EN-GJL 250 / 1.4460 |
| Casing Cover | Cast Iron / Stainless Steel | EN-GJL 250 / 1.4460 |
| Front Lining | Stainless Steel / Duplex | 1.4460 / 1.4517 |
| Rear Lining | Stainless Steel / Duplex | 1.4460 / 1.4517 |
| Shaft | Stainless Steel | 1.4021 / 1.4462 |
| Bearing Housing | Cast Iron / Stainless Steel | EN-GJL 250 / 1.4468 |
| Stuffing Box Body | Cast Iron / Stainless Steel | EN-GJL 250 / 1.4408 |
| Shaft Sleeve | Stainless Steel | 1.4404 / 1.4439 |
Andman S3 Pumps for Water & Wastewater Applications
1. Available for:
Industrial water circulation
Wastewater treatment
Filtration systems
2. Typical media:
Process water
Slightly contaminated water
Low solid content liquids
S3 150-330 Paper Pumps for Paper Production Line
1. High Efficiency
Optimized hydraulic design
Lower energy consumption
2. Fiber Handling Capability
Suitable for pulp suspension
Reduced clogging risk
3. Reliable Operation
Heavy-duty bearing design
Long service life
4. Easy Maintenance
Modular construction
Easy replacement of wear parts
Andman S3 150-330 Pumps Key Advantages
Robust bearing arrangement
Heavy-duty shaft design
Continuous operation capability
Minimize fiber damage
Reduce clogging risk
Replaceable wear components
Simple dismantling
Lower downtime
Andman with Most Suitable Pumping Solutions for Your Project
We do not only provide pumps, but also complete pumping solutions tailored to our customers' specific applications. With our engineering expertise and industry experience, we help customers select the right pump, optimize system performance, reduce operating costs and improve overall reliability, from pump selection and technical consultation to spare parts supply and after-sales support, we are committed to delivering reliable, efficient and cost-effective solutions for various industrial applications.
