Andman S100-265 Non Clogging Pulp Stock Pumps
Andman S Series S100-265 Non Clogging Paper Pumps are known for robust construction, wear resistance, high efficiency and maintenance-friendly design.
Andman S100-265 Pumps can pumping: Pulp suspension, White water, Process water, Slightly contaminated liquids, Chemical liquids, Fiber-containing liquids etc.
China Andman S100-265 Pulp Pumps are very popular in paper production processing:
Stock Preparation
Virgin pulp transfer
Recycled pulp circulation
Approach Flow System
Screening circulation
Cleaner feed
White Water System
White water circulation
Fiber recovery
Broke System
Broke pulp handling
Andman S Series Paper Pumps Advantages:
Good fiber handling capability
Reduced clogging risk
Stable continuous operation
Andman S100-265 Non Clogging Fiber Pumps Description
| Item | Description |
| Pump Model | Andman S100-265 |
| Pump Type | Single-stage centrifugal pump |
| Design | Horizontal, single-flow centrifugal pump |
| Application | Pulp, Paper, Industrial process liquids, Chemical, Food Processing etc |
| Impeller Type | Open / Semi-open / Closed depending on application |
Typical S series Pumps models include:
| S Series Pump Model | Typical Application |
| S80-265 | Small flow process water, pulp stock transfer |
| S100-265 | Paper mill process pumps, fiber suspension |
| S125-265 | Pulp & paper, chemical process |
| S100-350 | Medium flow pulp/process liquids |
| S125-350 | Paper stock, industrial liquids |
| S150-330 | Pulp circulation, process water |
| S125-400 | High flow pulp/process applications |
| S150-400 | Paper mill stock pumps |
| S200-380 | Larger pulp circulation duties |
| S150-470 | Higher head process pumping |
| S200-470 | Large paper/pulp applications |
| S250-430 | Large capacity industrial process pumping |
| S350-470 | High flow applications |
| S500-600 | Very large flow process service |
Andman S100-265 Non Clogging Paper Pumps Performance Parameters
| Parameter | Value (Typical Range) |
| Pump Type | Single-stage, single-suction centrifugal pump |
| Suction / discharge size | DN100 (depending on configuration) |
| Impeller diameter | ~265 mm |
| Flow rate (Q) | 50 – 250 m³/h |
| Head (H) | 10 – 60 m |
| Speed | Approx. 1450 – 2900 rpm |
| Efficiency | Up to 80–85% (depending on duty point) |
| Pressure rating | Up to around 16–25 bar depending on design |
| Pumping medium | Clean water, process water, slightly contaminated liquids, industrial fluids etc |
| Impeller Type | Open / Semi-open / Closed depending on application |
Andman S Paper Stock Pumps Typical Operating Points:
| Speed | Flow | Head | Power |
| 1450 rpm | 80–180 m³/h
|
15–35 m | 7.5–30 kW |
| 2900 rpm | 120–260 m³/h | 35-70 m | 30-75 kW |
Andman S10-265 Pumps in Mining Concentrator
Application Area: Process Water Supply System
Operating Conditions (Example):
Medium: Plant water / Recycled water
Flow rate: 150–250 m³/h
Head: 30–60 m
Pump Applications:
Flotation system make-up water
Cooling water for grinding area equipment
Mineral processing plant circulating water
Plant-wide water supply
China Andman S Series Pumps for Chemical Plant
Application Area: Process Liquid Transfer
Typical Operating Medium:
Process water
Coolant
Mildly corrosive liquids
Pump Applications:
Circulation systems
Cooling systems
Washing systems
If transporting corrosive media, materials such as stainless steel or duplex steel must be selected.
Where Andman S Series Non Clogging Horizontal Centrifugal Pumps can be used?
| Industry | Typical Usage |
| Pulp & Paper Industry | Process water circulation, white water handling, stock preparation auxiliary systems, cooling water circulation |
| Sugar Industry | Juice circulation, condensate transfer, cooling water, process liquid pumping |
| Mining Industry | Process water supply, plant water circulation, cooling systems, non-abrasive slurry transfer |
| Chemical Industry | Chemical liquid transfer, process circulation, washing systems |
| Water Treatment | Clean water pumping, filtration systems, wastewater treatment processes |
| Power Plants | Cooling water systems, auxiliary water systems, service water circulation |
| General Industry | Industrial water supply, HVAC systems, boiler feed auxiliary systems |
Andman Paper Stock Pumps for Paper Industry
Andman Paper pulp pumps are specialized pumps used in the papermaking industry to transport pulp stock, they are primarily utilized in processes such as pulp preparation, stock transport, paper machine stock supply systems, and waste paper processing. Due to characteristics such as high fiber content, high viscosity, the presence of impurities, and a tendency to cause clogging, standard centrifugal pumps generally fail to meet the requirements, necessitating the use of specially designed pulp pumps.
