Hydroman Sludge Pump Description
Hydroman® 150THY30-6P Hydraulic Slurry Pump is a vertical, underwater solution engineered for high-concentration slurry and sludge removal in the toughest environments. This 6 Inch Excavator Hydraulic Sludge Pump delivers reliable 30kW hydraulic power, transforming any standard excavator into a high-performance dredging unit. As an Excavator Mounted Hydraulic Slurry Dredging Pump, it eliminates the need for electric power, making it ideal for remote sites and deepwater operations. The Vertical Hydraulic Submersible Sludge Pump for Excavator features high-chrome wear parts and optional agitators for breaking up compacted solids. This Hydraulic Driven Slurry Pump for Underwater Operation is built to handle abrasive slurries, mud, and sand with minimal clogging and downtime. Contact Hydroman® today to boost your solids production!
This heavy-duty pump mounts directly onto the boom of hydraulic excavators, turning them into versatile dredging machines without requiring additional power sources. Powered entirely by the excavator's hydraulic system, it operates effectively in locations where electrical infrastructure is unavailable, such as remote mining sites, deepwater dredging zones, or flood-affected areas. The 150THY 30kW Submersible Slurry Sludge Pump delivers consistent, high-volume solids handling with low clogging rates, making it an indispensable tool for contractors facing challenging slurry conditions.
High-Chrome Wear-Resistant Construction – All wetted parts—including impeller, casing, and wear plates—are crafted from high-strength chromium alloy, offering exceptional resistance against abrasive wear from silica sand, gravel, and heavy slurry. This robust construction ensures a significantly extended service life in the harshest pumping conditions.
Integrated Agitator System – The pump is equipped with a powerful bottom agitator (with optional dual side cutters available) that actively breaks up settled solids, fluidizes compacted sediments, and creates a homogeneous slurry mixture before it enters the suction intake. This design effectively prevents clogging from bulky solids and ensures continuous, uninterrupted pumping.
Low-Speed Hydraulic Drive – Operating at low rotation speeds, the hydraulic motor minimizes wear on internal components while maximizing torque output. This low-RPM design translates directly into longer component life, reduced maintenance frequency, and lower total cost of ownership compared to high-speed electric alternatives.
Vertical Submersible Design – Engineered for full underwater operation, the vertical configuration allows the pump to be submerged directly into the slurry, eliminating suction lift limitations and priming requirements. This design ensures optimal performance even when working with deep settled solids or in fluctuating water levels.
Hydroman 150THY30-6p Hydraulic Pump Parameters
| Hydraulic Pump Specification | Hydraulic Motor Specification | |||||||
| Model | Outlet (mm) | Capacity (m³/h) | Head (m) | Power (KW) | Solids handling (mm) | Displacement (ml/r) | Pressure (Mpa) | Oil capacity (L/min) |
| 150THY30-6P | 150 | 100 | 35 | 30 | 55 | 80 | 23 | 80 |
| 150THY30-6P | 150 | 108 | 30 | 30 | 55 | 80 | 23 | 80 |
| 150THY30-6P | 150 | 150 | 30 | 30 | 30 | 80 | 23 | 80 |
| 150THY30-6P | 150 | 200 | 20 | 30 | 30 | 80 | 23 | 80 |
| 150THY30-6P | 150 | 200 | 25 | 30 | 30 | 80 | 23 | 80 |
| 150THY30-6P | 150 | 240 | 20 | 30 | 55 | 80 | 23 | 80 |
| 150THY30-6P | 150 | 250 | 20 | 30 | 55 | 80 | 23 | 80 |
Mining & Tailings Management
In mining operations, the Hydroman 150THY30-6P serves as an essential tool for tailings pond reclamation, sump cleaning, and high-concentration slurry transfer. The pump efficiently handles slurries exceeding 70% solids content by weight, dramatically reducing the amount of water processed and transported.
This high-solids capability increases overall productivity while lowering energy consumption and disposal costs. Whether extracting sand from settling ponds, relocating mill scale, or dewatering blast holes, this Heavy Duty Excavator Mounted Sludge Removal Pump delivers consistent, reliable performance that mechanical buckets simply cannot match.
Environmental Dredging & Waterway Maintenance
For contractors tasked with cleaning rivers, harbors, and industrial lagoons, this pump provides an unmatched combination of mobility and power. Mounted on an amphibious excavator or standard machine, it can access shallow waterways, confined spaces, and sensitive shorelines where traditional dredging equipment cannot operate.
The hydraulic drive eliminates electrical safety concerns in wet environments, while the agitator system ensures efficient removal of accumulated sediment without disturbing surrounding ecosystems. From port maintenance to dam dredging, this attachment pays for itself by completing jobs in hours rather than days.
Frequently Asked Questions About the Hydroman 150THY30-6P
Q1: What size excavator is compatible with the Hydroman 150THY30-6P?
The Hydroman 150THY30-6P is compatible with a wide range of excavator models, typically from 15 to 40 tons, including popular brands such as Caterpillar, Komatsu, Hitachi, Volvo, Kobelco, and Hyundai. The pump connects directly to the excavator's auxiliary hydraulic lines using standardized quick couplers. For optimal performance, the host excavator should provide adequate hydraulic flow and pressure to drive the 30kW pump motor efficiently. Hydroman® engineers can verify compatibility with your specific machine model before purchase.
Q2: What types of materials can this pump handle?
This pump is specifically engineered for abrasive and high-viscosity slurries. It effectively handles sand, gravel, mud, sludge, tailings, mill scale, bentonite, coal slurry, dredged sediment, and industrial wastewater containing solid particles. The high-chrome impeller and wear plates are designed to withstand continuous exposure to abrasive materials that would quickly destroy standard centrifugal pumps. With proper agitator configuration, the pump can also handle compacted sediments and materials with particle sizes up to 70mm.
Q3: How does the pump perform in deepwater conditions?
The vertical hydraulic submersible design allows the Hydroman 150THY30-6P to operate effectively at significant depths, with working depths exceeding 30 meters in many configurations. Unlike electric pumps that require specialized waterproof motors and long power cables, this hydraulic pump uses the excavator's existing hydraulic circuit, eliminating depth-related electrical hazards. The sealed hydraulic motor and double mechanical seal arrangement ensure reliable operation even when fully submerged, making it ideal for deep sumps, flooded excavations, and underwater dredging projects.
Ready to Transform Your Excavator into a Dredging Powerhouse?
The Hydroman 150THY30-6P Hydraulic Slurry Pump delivers unmatched solids handling, wear resistance, and operational flexibility. Whether you're cleaning tailings ponds, dredging harbors, or dewatering construction sites, this 6 Inch Excavator Hydraulic Sludge Pump will increase your productivity while reducing your operational costs. Don't let abrasive slurry slow down your project—contact Hydroman® today for a quote and technical consultation!
